IP2X-IK08 – CLASSE II
- LED Driver – Constant Current Supply.
- Progammable from 100 mA to 700 mA.
- Power: up to 100 W.
- Output voltage: up to 200 VDC.
- High resistance against network pollution.
- High reliability and long life duration.
- Very low inrush current – large number of Driver per cable.
- High energy efficiency and power factor (also during dimming process).
- Driver to install inside luminary.
- Direct Pilot Input (for association with Motion sensor).
- Additionnal energy saving (up to 65%) by dimming scenarios.
Advantages
Excellent reliability and long life.
Configurable to respond to your specific needs.
Possible distance between driver and source: up to 15m.
Numerous integrated dimming options to optimise energy savings.
Technical specifications:
DL-Pak 100L range-Sogexi
Energy saving certificates:
- Energy saving certificatest-Sogexi
- Makes it possible to obtain energy saving certificates:
- RES-EC-101 > 2.0 kWh cumac x P(W).
- RES-EC-102 > 1.6 kWh cumac x P(W).
- RES-EC-103 > 8.0 kWh cumac x P(W).
- RES-EC-104 > case 1: 9300 kWh cumac x N lighting fixtures > case 2: 7200 kWh cumac x N lighting fixtures.
